Absolute ALTA Wireless Infrared Motion Sensor – AA Powered, 900MHZ

Motion sensors use passive infra-red (PIR) technology to monitor for a variety of different needs. The 60° beam width is best for use in typical security types of monitoring. Human bodies or med/large sized animals can be detected at a range of up to 5 meters, alerting you when someone (or something) is where it shouldn’t be. Use the 100° version of the sensors for tracking applications. Designed to be placed under a desk, a cubicle, a conference room table, the sensor can be implemented by companies as part of room scheduling and space booking programs, showing what desks are available/unoccupied within a building, how effectively space is being utilized or underutilized, etc.

Monnit MNS2-9-W2-MS-IR Features

1,200+ foot range

12+ year battery life

80+ wireless sensors

Bank-level AES security

Up in 15 easy setup

Global ready (900, 920, 868 & 433 MHz)

Infrared Motion Sensing Element Specifications

Current Consumption: Type: 170 µA Max: 300 µA

Wake-up Time: 30 Seconds

Variation Specifications

Sensing Range: 15 ft (4.5 m)/12 ft (3.7 m)/9 ft (2.7 m)

Security: Encrypt-RF® (256-bit key exchange and AES-128 CTR)

Weight: 2.9 oz. (82.21 g)

Supply Voltage: 2.0–3.8 VDC (3.0–3.8 VDC using power supply)

Optimal Battery Operating Temperature: +10°C to +50°C (+50°F to +122°F)

Data Logging (iMonnit Premiere): Datalogs 2000 to 4000 readings if gateway connection is lost (non-volatile flash, persists through the power cycle): 10-minute heartbeats = ~ 22 days2-hour heartbeats = ~ 266 days

Sensing Method: Quad Array Passive Infrared (PIR) Sensing Element

Response Time: 1 to 3 Seconds

Storage Temperature:: -40°C to 85°C (-40°F to 185°F)

Visual Confirmation: Standard LensViewing Angle: 60°Range: 15ft (4.57m)/12ft (3.65 m)/9ft. (2.74 m)

Visual Confirmation: Wide-Angle LensViewing Angle: 100°Range: 15ft. (4.57m)/12ft. (3.65m)/9ft. (2.74m)

ALTA AA Specifications

Battery Type: 2 Replaceable AA 1.5 V Batteries

Dimension: 4.375 in x 2.470 in x 1.12 in

Supply Voltage: 2.0 – 3.8 V (2 x AA 1.5V Batteries or Optional Power Supply)

Battery Life: At 1 hour heartbeat setting, AA batteries will last up to 10 years.**

Max Operating Temperature Using AA Alkaline: -18°C to 55°C (0°F to 130°F)

Max Operating Temperature Using AA Lithium: -40°C to 60°C (-40°F to 140°F)

Optimal Battery Operating Temperature: +10°C to +50°C (+50°F to +122°F)

Enclosure Material: ABS

ALTA 900 MHz Specifications

Operating Frequency: 900 MHz Operating Frequency

Certifications: Complies with Part 15 of the FCC Rules. (FCC ID: ZTL-G2SC1)Complies with Industry Canada standards. (IC: 9794A-G2SC1)

Device Range: Device Range Up to 1,200 ft. non-line-of-sight, wireless device range*

Security: Encrypt-RF® (Diffie-Hellman Key Exchange + AES-128 CBC)
